Description:

The lightest chainsaw in its class, ideal for storm clean up and mid size tree felling, it powers through with reliability and productivity.

• TOP FEATURES
• i-30™ starter reduces starting effort by 30%
• Multiple-stage air filtration system cleans air and reduces air filter maintenance
• 34.4 cc professional-grade, 2-stroke engine

Features:

Fit More Work in the Workday:

• 34.4 cc professional-grade, 2-stroke engine for outstanding performance and durability.
• Lightest chainsaw in its class with a high power-to-weight ratio that reduces fatigue and increases productivity.
• i-30™ starting system reduces starting effort by 30%.
• Three-point spring vibration-reduction system delivers operator comfort.
• Multiple-stage air filtration system cleans air and reduces maintenance.
• Automatic clutch-driven oiler operates only when the chain is moving to reduce oil consumption.
• Momentary stop switch automatically returns to the "ON" position.
• Provides 17% more power than the CS-3410 model.
• Translucent fuel tank for quick fuel level checks.

Specifications:

• Engine Displacement (cc): 34.4
• Engine Displacement (cu in): 2.1
• Starting System: i-30™
• Ignition System: Digital
• Oiling System: Automatic Clutch-Driven
• Vibration Reduction System: 3-Point Spring System
• Available Bar Lengths (in): 16
• Oil Capacity (fl. oz.): 7.8
• Dry Weight (lb): 8.2
• Sprocket Cover: Plastic
• Bar Type: Laminated
• Sprocket Type: Spur
• Handle: Plastic
• Fuel Capacity (fl. oz.): 9.5
• Carburetor (w/Purge Pump): Yes
• Warranty: 5-year consumer / 1-year commercial

Description:

The CS-355T is ECHO's most powerful top-handle chainsaw combining professional-grade power with ergonomic, user-friendly features. It delivers all-day productivity without all-day exhaustion.

• TOP FEATURES
• ECHO’s highest-power top-handle chainsaw
• Heavy-duty air filter provides superior air filtration
• 35.8 cc professional-grade, 2-stroke engine

Features:

• ARBORIST-APPROVED
• 35.8 cc professional-grade, 2-stroke engine
• For outstanding performance and durability
• Contoured handle
• Ergonomic shape to fit operator's hand and increase comfort
• Adjustable-size palm rest
• Supports hand and provides leverage
• Unique handle angle
• Provides a natural wrist position while cutting
• Automatic, adjustable clutch-driven oiler
• Operates only when the chain is moving to reduce oil consumption
• Reduced-effort starting system
• Provides easier starts
• Available in 14 in. and 16 in. bar lengths
• For large limbing applications

Specification:

Engine:

• Engine Displacement: 35.8 cc (2.19 cu in)
• Starting System: Spring-Assist
• Ignition System: Digital
• Oiling System: Automatic/Adjustable (Clutch-Driven)
• Vibration Reduction System: Standard

Bar and Chain:

• Available Bar Lengths: 14 in, 16 in
• Bar Type: Pro91®
• Sprocket Type: Spur
• Sprocket Cover: Plastic

Other Specifications:

• Oil Capacity: 243 ml (8.2 fl. oz.)
• Dry Weight: 8 lbs (3.6 kg) without bar and chain
• Handle: Plastic
• Fuel Capacity: 331 ml (11.2 fl. oz.)
• Carburetor: Butterfly-Valve Diaphragm (with Purge Pump)
• Warranty: 5 years consumer / 1 year commercial

Description:

When a paycheck depends on performance, the pros reach for the CS-680. With 66.8 ccs of professional-grade ECHO power and available 20, 24 and 27 in. Performance Cutting System™ bar upgrades, it cuts the toughest jobs down to size.

• TOP FEATURES
• 66.8 cc professional-grade, 2-stroke engine
• Performance Cutting System™
• Aluminum handle with rubber grip

Features:

• Extreme Echo Power:
• 66.8 cc professional-grade, 2-stroke engine for outstanding performance and durability.
• Performance Cutting System™ with upgraded bar and aggressive chain for improved cutting performance.
• Aluminum handle with rubber grip improves comfort and control.
• Automatic, adjustable oiler with manual override allows matching cutting conditions for reduced oil consumption.
• Heavy-duty, easy-access, automotive-style air filter provides superior filtration with reduced maintenance time.
• Side-access chain tensioner for easy chain adjustments.
• Available in 20, 24, and 27-inch bar lengths, perfect for large jobs.

Specifications:

• Engine Displacement (cc): 66.8
• Engine Displacement (cu in): 4.07
• Starting System: Standard
• Ignition System: SAIS (Semi-Automatic Ignition System)
• Oiling System: Automatic/Adjustable (with manual override)
• Vibration Reduction System: Standard
• Available Bar Lengths (in): 20, 24, 27
• Oil Capacity (fl. oz.): 12.5
• Dry Weight (lb): 14.6
• Sprocket Cover: Plastic
• Bar Type: PowerMatch
• Sprocket Type: Rim
• Handle: Aluminum with Rubber Grip
• Fuel Capacity (fl. oz.): 21.6
• Carburetor (w/Purge Pump): Butterfly-Valve Diaphragm (without purge pump)
• Warranty: 5 year consumer / 1 year commercial

Description:

The CS-7310P Chainsaw is not only ECHO’s most powerful chainsaw in North America but it has the features arborists and loggers need to tackle tough jobs. Whether you're tree felling or firewood harvesting, the CS-7310P is powerful, durable, and ready to work as long as you do.

• TOP FEATURES
• 73.5 cc professional-grade, 2-stroke engine
• Professional-grade magnesium sprocket cover and crankcase
• Four-stage air filtration system cleans air and reduces air filter maintenance

Features:

• The Most Powerful ECHO Chainsaw:
• High-power 73.5 cc professional-grade, 2-stroke engine for outstanding performance and durability.
• Four-stage air cleaner system cleans intake air and reduces air filter maintenance.
• Decompression valve reduces rope-pulling effort for easier starts.
• Automatic, adjustable clutch-driven oiler operates only when the chain is moving to reduce oil consumption.
• 19 mm captive bar nuts prevent loss of hardware.
• Three-point spring vibration-reduction system delivers operator comfort.
• Aluminum handle with rubber grip provides lightweight strength and improved control.
• Winter operation plug adjusts opening to air box for improved operation in summer or winter.
• Available in either .050 in. or .058 in. gauge chain.

Specifications:

• Engine Displacement (cc): 73.5
• Engine Displacement (cu in): 4.49
• Starting System: Standard
• Ignition System: Digital ignition system
• Oiling System: Automatic/Adjustable
• Vibration Reduction System: Standard
• Available Bar Lengths (in): 20, 24, 28, 32
• Oil Capacity (fl. oz.): 12.2
• Dry Weight (lb): 14.8
• Sprocket Cover: Magnesium
• Bar Type: PowerCut™
• Handle: Aluminum with Rubber Overmold
• Fuel Capacity (fl. oz.): 27.1
• Warranty: 5-year consumer / 1-year commercial

DESCRIPTION

Lightweight construction with oversized power. The top-handle CS-2511T is in a class of its own, ideal for arborists who need sky-high performance in sky-high places.

SPECIFICATIONS

• Engine Displacement: 25 cc
• Engine Displacement: 1.53 cu. in.
• Starting System: Spring-Assist
• Ignition System: Digital
• Oiling System: Automatic/Adjustable
• Vibration Reduction System: Standard
• Available Bar Lengths: 12, 14 in.
• Oil Capacity: 4.7 fl. oz.
• Dry Weight: 5.2 lb.
• Sprocket Cover: Plastic
• Bar Type: Double-Guard 91
• Sprocket Type: Spur
• Handle: Plastic
• Fuel Capacity: 6.4 fl. oz.
• Warranty: 5 year consumer / 1 year commercial
• MSRP: $499.99 - $509.99

TOP FEATURES

• Choke with automatic fast idle for easy starting
• Clutch-driven adjustable oiler
• 25.0 cc professional-grade, 2-stroke engine

FEATURES - LIGHTEST GAS CHAINSAW IN NORTH AMERICA

• 25.0 cc professional-grade, 2-stroke engine: For outstanding performance and durability
• Textured grip handles: For optimum saw control
• Fine grid starter cover: Prevents debris ingestion and prolongs air filter life
• Clutch-driven adjustable oiler: Operates only when the chain is moving to reduce oil consumption
• Choke with automatic fast idle: Provides for easy starting
• Side-access chain tensioner: For easy chain adjustments
• G-Force Engine Air Pre-Cleaner™: Extends air filter life and reduces maintenance intervals
• Dual-post chain brake: For increased durability
• Large fuel and oil caps: Can be loosened and tightened with starter handle

Description:

Lightweight construction with oversized power. The top-handle CS-2511T is in a class of its own, ideal for arborists who need sky-high performance in sky-high places.

TOP FEATURES:

• Choke with automatic fast idle for easy starting
• Clutch-driven adjustable oiler
• 25.0 cc professional-grade, 2-stroke engine

FEATURES:

• LIGHTEST GAS CHAINSAW IN NORTH AMERICA
• 25.0 cc professional-grade, 2-stroke engine
• For outstanding performance and durability
• Textured grip handles
• For optimum saw control
• Fine grid starter cover
• Prevents debris ingestion and prolongs air filter life
• Clutch-driven adjustable oiler
• Operates only when the chain is moving to reduce oil consumption
• Choke with automatic fast idle
• Provides for easy starting
• Side-access chain tensioner
• For easy chain adjustments
• G-Force Engine Air Pre-Cleaner™
• Extends air filter life and reduces maintenance intervals
• Dual-post chain brake
• For increased durability
• Large fuel and oil caps
• Can be loosened and tightened with starter handle

Specifications:

• Engine Displacement (cc): 25
• Engine Displacement (cu in): 1.53
• Starting System: Spring-Assist
• Ignition System: Digital
• Oiling System: Automatic/Adjustable
• Vibration Reduction System: Standard
• Available Bar Lengths (in): 12, 14
• Oil Capacity (fl. oz.): 4.7
• Dry Weight (lb): 5.2
• Sprocket Cover: Plastic
• Bar Type: Double-Guard 91
• Sprocket Type: Spur
• Handle: Plastic
• Fuel Capacity (fl. oz.): 6.4
• Warranty: 5 years consumer / 1 year commercial

Description:

Mini in size, but mighty in strength. Despite weighing only 6.6 lbs., the CS-271T surprises with incredible torque and instant throttle response, helping make light work of long days spent pruning and trimming branches.

Features:

• i-30™ starter reduces starting effort by 30%
• G-Force Engine Air Pre-Cleaner™ for reduced air filter maintenance
• 26.9 cc professional-grade, 2-stroke engine

Specifications:

• Engine Displacement (cc): 26.9
• Engine Displacement (cu in): 1.64
• Starting System: i-30™
• Ignition System: Digital
• Oiling System: Automatic/Adjustable (Clutch-Driven)
• Vibration Reduction System: Standard
• Available Bar Lengths (in): 12
• Oil Capacity (fl. oz.): 5.4
• Dry Weight (lb): 6.6
• Sprocket Cover: Plastic
• Bar Type: Double-Guard 91
• Sprocket Type: Spur
• Handle: Plastic
• Fuel Capacity (fl. oz.): 8.1
• Carburetor (w/Purge Pump): Butterfly-Valve Diaphragm
• Warranty: 5 year consumer / 1 year commercial

CS-303T

Power with agility. Whether on the ground or in the tree, the top-handle CS-303T was made to meet the demanding needs of professional arborists. It starts easily and reliably, while smart design features ensure smooth, productive workdays.

TOP FEATURES

• Proven design and an increase in power over the CS-271T
• Heavy-duty air filter provides superior air filtration
• 30.1 cc professional-grade, 2-stroke engine
• 12" Bar

Description:

Power with agility. Whether on the ground or in the tree, the top-handle CS-303T was made to meet the demanding needs of professional arborists. It starts easily and reliably, while smart design features ensure smooth, productive workdays.

TOP FEATURES:

Proven design and an increase in power over the CS-271T Heavy-duty air filter provides superior air filtration 30.1 cc professional-grade, 2-stroke engine

FEATURES:

• 30.1 cc professional-grade, 2-stroke engine: Delivers outstanding performance and durability.
• Extended top handle: Provides greater reach, maneuverability, and control, enhancing user comfort and efficiency.
• Vibration-reduction system: Reduces operator fatigue by minimizing vibrations during operation.
• Automatic, adjustable oiler: Matches cutting conditions to reduce oil consumption, ensuring optimal lubrication for the chain.
• Side-access chain tensioner: Allows for easy adjustments to maintain proper chain tension, enhancing cutting performance and safety.
• Metal lanyard ring: Increases durability and facilitates easy attachment and detachment of accessories.
• Available in 12 in. and 14 in. bar lengths: Offers versatility for various limbing applications, allowing users to choose the appropriate size for their needs.

SPECIFICATION:

• Engine Displacement (cc): 30.1
• Engine Displacement (cu in): 1.84
• Starting System: Standard
• Ignition System: CDI
• Oiling System: Automatic/Adjustable (Clutch-Driven)
• Vibration Reduction System: Standard
• Available Bar Lengths (in): 14
• Oil Capacity (fl. oz.): 5.1
• Dry Weight (lb): 7.7
• Sprocket Cover: Plastic
• Bar Type: Double-Guard 91
• Sprocket Type: Spur
• Handle: Plastic
• Fuel Capacity (fl. oz.): 8.5
• Carburetor (w/Purge Pump): Butterfly-Valve Diaphragm
• Warranty: 5 year consumer / 1 year commercial

FEATURES

• 34.4 CC PROFESSIONAL-GRADE, 2-STROKE ENGINE: For outstanding performance and durability
• LIGHTEST CHAINSAW IN ITS CLASS: High power-to-weight ratio reduces fatigue and increase productivity
• I-30™ STARTING SYSTEM: Reduces starting effort by 30%
• INTEGRATED CHOKE AND FAST IDLE: Trigger release mechanism allows for fast starts
• TRANSLUCENT FUEL AND OIL TANKS: For quick fuel and oil level checks
• AUTOMATIC CLUTCH-DRIVEN OILER: Operates only when the chain is moving to reduce oil consumption
• MOMENTARY STOP SWITCH: Automatically returns to "ON" position
• SIDE-ACCESS CHAIN TENSIONER: For easy chain adjustments
• PURGE BULB: Delivers fresh fuel to carburetor for easier starts

SPECIFICATIONS

GENERAL INFORMATION

Manufacturer

Echo

Model

CS-3410 - 16 in.

Model Code

NA

Color

Orange

BODY

Housing

Sprocket cover - Plastic

Sprocket type - Spur

Handle

Plastic

DIMENSIONS

Length

Available bar - 16 in.

Weight

Dry - 8.2 lb.

ENGINE

Engine

Professional-grade, 2-stroke

Displacement

34.4 cc (2.1 ci)

Starter

i-30™

Carburetion

Purge pump

Fuel Tank Capacity

9.5 fl. oz.

Oil Capacity

7.8 fl. oz.

OPERATIONAL

Guide Bars

Laminated

OTHER

Miscellaneous

Ignition system - Digital

Oiling system - Automatic Clutch-Driven

Vibration reduction system - 3-Point Spring System

Warranty

Consumer - 5 year

Commercial - 1 year

Description:

The hardest worker on any property. Available with a 16 in. bar, the popular 34-cc CS-352 is a more powerful version of the ECHO CS-310. With a host of user-friendly features, it enhances productivity at any house, ranch or jobsite.

Features:

• i-30™ starter reduces starting effort by 30%
• Tool-less, easy-access air filter
• 34 cc professional-grade, 2-stroke engine

Specifications:

• Engine Displacement (cc): 34
• Engine Displacement (cu in): 2.08
• Starting System: i-30™
• Ignition System: Digital
• Oiling System: Automatic (Clutch-Driven)
• Vibration Reduction System: Standard
• Available Bar Lengths (in): 16
• Oil Capacity (fl. oz.): 8.8
• Dry Weight (lb): 8.8
• Sprocket Cover: Plastic
• Bar Type: Double-Guard 91
• Sprocket Type: Spur
• Handle: Plastic
• Fuel Capacity (fl. oz.): 8.5
• Carburetor (w/Purge Pump): Butterfly-Valve Diaphragm
• Warranty: 5 year consumer / 1 year commercial

Description:

A simply reliable cutting machine. Whether the work calls for seemingly endless storm cleanup or bucking loads of firewood, the CS-4510 delivers power and performance for the long haul.

Features:

• 45.0 cc professional-grade, 2-stroke engine
• Spring-assist starter reduces starting effort
• Heavy-duty air filter with tool-less access provides superior air filtration

Specifications:

• Engine Displacement (cc): 45
• Engine Displacement (cu in): 2.75
• Starting System: Spring-Assist
• Ignition System: Digital
• Oiling System: Automatic/adjustable
• Vibration Reduction System: Standard
• Available Bar Lengths (in): 16, 18
• Oil Capacity (fl. oz.): 11.1
• Dry Weight (lb): 11.1
• Sprocket Cover: Plastic
• Bar Type: Laminated
• Sprocket Type: Spur
• Handle: Rear
• Fuel Capacity (fl. oz.): 16.2
• Carburetor (w/Purge Pump): Butterfly-Valve Diaphragm
• Warranty: 5 year consumer / 1 year commercial

Description:

The CS-4920 features a powerful 50.1 cc, 2-stroke engine but is the lightest saw in its class. With a purge bulb for easier starts and a momentary switch that returns to the "ON" position when the saw is shut off, the CS-4920 is simple to operate.

Features:

• 50.1 cc professional-grade, 2-stroke engine
• Momentary stop switch
• Heavy-duty air filter with tool-less access provides superior air filtration

Specifications:

Engine and Performance

• Engine Displacement: 50.1 cc
• Ignition System: Digital
• Oiling System: Automatic/adjustable
• Vibration Reduction System: Spring

Cutting System

• Available Bar Lengths: 16 in, 18 in, 20 in

Capacities

• Oil Capacity: 11.2 fl. oz.
• Fuel Capacity: 16.2 fl. oz.

Physical Specifications

• Dry Weight: 11.1 lb
• Handle: Plastic

Warranty

• Consumer Warranty: 5 years
• Commercial Warranty: 1 year

Description:

The CS-4920 features a powerful 50.1 cc, 2-stroke engine but is the lightest saw in its class. With a purge bulb for easier starts and a momentary switch that returns to the "ON" position when the saw is shut off, the CS-4920 is simple to operate.

• TOP FEATURES:
• 50.1 cc professional-grade, 2-stroke engine
• Momentary stop switch
• Heavy-duty air filter with tool-less access provides superior air filtration

Description:

CS-501P Features:

• 50.2 cc professional-grade, 2-stroke engine
• Automatic, adjustable clutch-driven oiler – reduces oil consumption
• Captive bar nuts – no chance of losing fasteners
• Decompression valve – for easier starting
• Ergonomic aluminum front handle – for improved comfort and maneuverability
• G-Force Engine Air Pre-Cleaner™ – reduces air filter maintenance
• Professional-grade bar and chain – for maximum cutting performance and durability
• Top-mounted, tool-less access, two piece air filter

Specifications:

• Engine Displacement (cc): 50.2
• Oil Capacity (fl oz): 9.5
• Engine Displacement (cu in): 3.06
• Dry Weight (lbs): 10.6 (Without bar and chain)
• Starting System: Standard
• Sprocket Cover: Plastic
• Ignition System: Digital
• Bar Type: Pro-Lite®
• Carburetor: Butterfly-Valve Diaphragm (without purge pump)
• Sprocket Type: Rim
• Oiling System: Automatic/Adjustable (Clutch-Driven)
• Handle: Aluminum
• Vibration Reduction System: Standard
• Fuel Capacity (fl. oz.): 16.6
• Available Bar Lengths (in): 18, 20
• Warranty: 1 year commercial / 5 years consumer.

Description:

The icon. A professionally productive beast. No other saw has a reputation like the CS-590 Timber Wolf because no other saw can perform like it. A lightweight, professional-grade 59.8 cc engine provides the confidence and performance needed to tame the toughest jobs.

Features:

• G-Force Engine Air Pre-Cleaner™ for reduced air filter maintenance
• Heavy-duty air filter with tool-less access provides superior air filtration
• 59.8 cc professional-grade, 2-stroke engine

Specifications:

• Engine Displacement: 59.8 cc
• Engine Displacement: 3.64 cu in
• Starting System: Standard
• Ignition System: Digital
• Oiling System: Automatic/Adjustable (Clutch-Driven)
• Vibration Reduction System: Standard
• Available Bar Lengths: 18 in, 20 in, 24 in
• Oil Capacity: 10.2 fl. oz.
• Dry Weight: 13.2 lb
• Sprocket Cover: Plastic
• Bar Type: Pro-Lite w/ ProAm material
• Sprocket Type: Spur
• Handle: Plastic
• Fuel Capacity: 21.8 fl. oz.
• Carburetor (w/Purge Pump): Butterfly-Valve Diaphragm (without purge pump)
• Warranty: 5 year consumer / 1 year commercial
